- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS On-Line
- Packaged Quantity
- 1 Pack
- Product Type
- Double Conversion Online UPS
- Technical Information
- Plug/Connector Type
- Hard Wire 3-wire (1P + N + E)
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Hard Wire 3-wire (1P + N + E)
- Receptacle Detail
- 6 x IEC 60320 C13
- 6 x IEC 60320 C19
- 1 x Hard Wire 3-wire (1P + N + E)
- Phase
- Single Phase
- Efficiency
- 96%
- Power Description
- Load Capacity (VA)
- 10 kVA
- Load Capacity (Watt)
- 10 kW
- Input Voltage
- 230 V AC
- Input Voltage Range
- 220 V AC - 240 V AC
- Output Voltage
- 220 V AC
- 230 V AC
- 240 V AC
- Input Frequency
- 40 Hz
- 70 Hz
- Output Frequency
- 50 Hz
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 1410 J
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- Network Card
- Interfaces/Ports
- USB
- Yes
- EPO Port
- Yes
- Battery Information
- DC System Voltage
- 180 V DC
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Battery Energy
- 4898.9 kJ
- Backup/Run Time (Full Load)
- 5.86 Minute
- Backup/Run Time (Half Load)
- 12.51 Minute
- Typical Battery Recharge Time
- 1.50 Hour
- Replaceable Battery
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Maximum Operating Elevation
- 3.05 km
- Maximum Storage Elevation
- 15.24 km
- Storage Relative Humidity
- 0% - 95%
- Sound Emission
- 55 dB
- Thermal Dissipation
- 1900 BTU/h
- Physical Characteristics
- Product Color
- Silver
- Grey
- Form Factor
- Rack/Tower
- Rack Height
- 4U
- Height
- 175 mm
- Width
- 432 mm
- Depth
- 832 mm
- Weight (Approximate)
- 55 kg
- Miscellaneous
- Certifications & Standards
- CE Mark
- UKCA
- EN/IEC 62040-1
- EN/IEC 62040-2
- IEC 62040-2
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- China Restriction of Hazardous Substances (China RoHS)
