QNAP TDS-H2489FU-R2-4314-512G SAN/NAS Storage System

  • Part: 1365088
  • Model: TDS-H2489FU-R2-4314-512G
$46,254.00

Availability

Out of Stock

The flagship TDS-h2489FU R2 U.2 NVMe all-flash rackmount NAS, powered by dual Intel® Xeon® Silver 4300 series processors in 16/32-core configurations, delivers a highly efficient, secure, and reliable enterprise storage solution. Its robust performance meets the demands of virtualization, data centers, AI Big Data storage, cloud-based applications, and 3D rendering workstations, addressing the need for low-latency and high-load multitasking applications. The 24-bay TDS-h2489FU R2 comes with sixteen 2.5-inch U.2 PCIe NVMe slots and eight 2.5-inch U.2 PCIe NVMe / SATA 6Gbps slots, along with four PCIe Gen 4 expansion slots for quickly upgrading to 25GbE / 100GbE networking and PB-level storage, supporting high-speed data access and data growth. Dual redundant power supplies minimize the risk of unexpected hardware failure, ensuring stable system operation.

Scalable ECC RDIMM memory up to 1TB

Equipped with error-correcting DDR4 ECC RDIMM memory, expandable up to 1TB, boosting multitasking performance.

25GbE as standard and upgradable to 100GbE

Enable Port Trunking and connect to a network switch to expand bandwidth for more devices and workstations.

High expandability with PCIe Gen 4

Has four PCIe Gen 4 slots, allowing installing high-speed network cards (10/25/100GbE), M.2 SSD expansion cards, Fibre Channel cards, and storage expansion cards.

Petabyte-scale storage

Flexibly connect QNAP PCIe JBOD or SAS JBOD for higher capacity, exceptional performance, and flexible expandability.

M.2 SSD caching

Two M.2 PCIe NVMe / SATA slots for cache acceleration or high-speed storage pools, enhancing performance and data access speed.

Immutability

Uses the ZFS-based QuTS hero operating system, which ensures high data integrity with immutable storage, snapshot protection, data deduplication, and SSD optimization.

Unmatched on-demand performance, seamlessly powering critical applications. | Virtualization

Eliminates storage bottlenecks for unstructured data and I/O intensive workloads; ideal for server virtualization and virtual desktop infrastructure (VDI).

Data Centers

Delivers ultra-low latency and high IOPS performance, providing response times within microseconds for data centers that host significant business-critical systems and data.

Media and Entertainment (M&E) production

Satisfies smooth 4K/8K media streaming and post-production, empowering multimedia workflows with faster data transfer, access, and backup for boosted efficiency.

  • General Information
    • Manufacturer
    • QNAP Systems
    • Manufacturer Website Address
    • http://www.qnap.com
    • Brand Name
    • QNAP
    • Product Type
    • SAN/NAS Storage System
  • Warranty
    • Limited Warranty
    • 5 Year

  • Storage
    • Number of Hard Drives Supported
    • 24
    • Number of Hard Drives Installed
    • 0
    • Number of Solid State Drive Supported
    • 24
    • Number of Solid State Drive Installed
    • 0
    • Flash Memory Capacity
    • 5 GB
  • Processor & Chipset
    • Number of Processors Installed
    • 2
    • Processor Manufacturer
    • Intel
    • Processor Type
    • Xeon Silver
    • Processor Model
    • 4314
    • Processor Core
    • Hexadeca-core (16 Core)
  • Memory
    • Standard Memory
    • 512 GB
    • Memory Technology
    • DDR4 SDRAM
  • Network & Communication
    • Ethernet Technology
    • 25 Gigabit Ethernet
    • 2.5 Gigabit Ethernet
  • I/O Expansions
    • Number of Total Expansion Bays
    • 24
    • Number of 2.5" Bays
    • 24
    • Total Number of Expansion Slots
    • 4
    • Expansion Slot Type
    • PCI Express 4.0 x16
    • PCI Express 4.0 x8
    • SFP28
  • Controllers
    • Controller Type
    • Serial ATA/600
    • NVMe
    • RAID Supported
    • Yes
    • RAID Levels
    • 0, 1, 5, 6, 10, 50, 60, JBOD
  • Interfaces/Ports
    • Total Number of USB Ports
    • 4
    • Number of USB 3.2 Gen 1 Ports
    • 4
    • Network (RJ-45)
    • Yes
    • Number of Network (RJ-45) Ports
    • 4
  • Software
    • Operating System
    • QTS 5.2.6
    • Operating System Supported
    • Mac OS X 10.10 Yosemite
    • Ubuntu 14.04
    • CentOS 7.0
    • Red Hat Enterprise Linux 6.6
    • SUSE Linux Enterprise Server 12
    • Linux
    • AIX 7
    • Solaris 10
    • Windows 7
    • Windows 8
    • Windows 10
    • Windows 11
    • Windows Server 2008 R2
    • Windows Server 2012
    • Windows Server 2012 R2
    • Windows Server 2016
    • Windows Server 2019
    • Windows Server 2022
    • Windows Server 2025
  • Management & Protocols
    • Protocols
    • LDAP
    • HTTPS
    • L2TP
    • SFTP
    • DHCP
    • SSH
    • IPSec
    • FTPS
    • AFP
    • CIFS/SMB
    • FTP
    • SNMPv2
    • IPv4
    • WEBDAV
    • Telnet
    • SSL
    • iSCSI
    • TLS
    • NFS
    • HTTP
    • TFTP
    • FXP
    • DDNS
    • IPv6
    • PPTP
    • SNMPv3
    • RSync
  • Power Description
    • Number of Power Supplies Installed
    • 2
    • Maximum Power Supply Wattage
    • 1.20 kW
    • Redundant Power Supply
    • Yes
  • Physical Characteristics
    • Height
    • 88.3 mm
    • Width
    • 446.2 mm
    • Depth
    • 713.2 mm
    • Form Factor
    • Rack-mountable
    • Weight (Approximate)
    • 22.77 kg
  • Miscellaneous
    • Package Contents
      • TDS-H2489FU-R2-4314-512G SAN/NAS Storage System
      • 1 x Ethernet Cable
      • 2 x Power Cord
      • 2 x Flat head screw (for M.2 SSD)
      • 96 x Flat head screw (for 2.5" HDD)
      • Hard disk tray key
      • Quick Installation Guide (QIG)
