Vertiv Liebert GXT5LI-3000IRT2UXL 3000VA Rack/Tower UPS

  • Part: 1354428
  • Model: 01202665
$1.00

Availability

Out of Stock

The Vertiv™ Liebert GXT5 Lithium-Ion UPS provides the highest level of power protection for your business critical IT applications.

High Performance Online Power Protection

The GXT5 Lithium-Ion double conversion online UPS provides both the highest level of power conditioning and battery backup for business critical IT equipment such as business network gear and servers ensuring your mission-critical applications are protected in the event of an unanticipated loss of power or an unprecedented power surge.

The GXT5 Lithium-Ion UPS protects against the widest range of power fluctuations and automatically switches to battery backup when power loss is detected. With a 0.9 or better output power factor (PF) and no transfer time to operation on battery, you can ensure your most critical assets are protected.

The rack/tower convertible design of the Vertiv Liebert GXT5 Lithium-Ion UPS makes it ideal for edge or distributed IT applications where floor space is at a premium. It is a true low-maintenance, set-it and forget-it solution ideal for remote locations with limited onsite technical resources.

Vertiv Liebert GXT5 Lithium-Ion Overview

  • 1000VA, 1500VA, 2000VA, & 3000VA UPSs in a rack/tower convertible form factor
  • Standard 5-year warranty provides peace of mind that your investment is protected against potentially costly equipment failures
  • Achieve the lowest total cost of ownership over the lifetime of the UPS with fewer battery replacements and up to 10 years of useable life
  • Hot-swappable, user-replaceable batteries increase the useable life of the UPS by allowing you to easily replace the batteries without disrupting power to connected equipment
  • Internal batteries offer industry-leading runtime (up to 14 minutes at full load) to protect critical equipment during an unexpected power loss
  • Lithium-Ion battery technology offers better performance in high temperature environments, supports up to 10 times more discharge cycles, and delivers faster recharge times compared to VRLA batteries
  • General Information
    • Manufacturer
    • Vertiv
    • Manufacturer Website Address
    • http://www.vertiv.com/
    • Brand Name
    • Vertiv Liebert
    • Product Series
    • GXT5
    • Packaged Quantity
    • 1 Each
    • Product Type
    • Double Conversion Online UPS
  • Warranty
    • Limited Warranty
    • 5 Year
    • Additional Warranty Information
    • 5 years on UPS and Battery

  • Technical Information
    • Plug/Connector Type
    • IEC 60320 C20
    • Receptacle Type
    • IEC 60320 C19
    • IEC 60320 C13
    • Receptacle Detail
    • 1 x IEC 60320 C19
    • 6 x IEC 60320 C13
    • Transfer Time
    • 0 ns
    • Efficiency Detail
    • 95% (Online Mode)
    • 98% (ECO Mode)
    • Application/Usage
    • Business
    • Mission Critical Equipment
    • IT
    • IT Equipment
    • Surge Suppression
    • Yes
    • Features
    • Audible/Visual Alarm
  • Power Description
    • Load Capacity (VA)
    • 3 kVA
    • Load Capacity (Watt)
    • 2.70 kW
    • Input Voltage
    • 230 V AC
    • 120 V AC
    • Input Voltage Range
    • 176 V AC - 288 V AC
    • 115 V AC - 288 V AC
    • Output Voltage
    • 200 V AC
    • 208 V AC
    • 220 V AC
    • 230 V AC
    • 240 V AC
    • Waveform Type
    • Pure Sine Wave
    • Output Power Factor
    • 0.9
  • Display & Graphics
    • Display
    • LCD
  • Management
    • Network Management
    • SNMP/Web
    • BACnet/Modbus
    • Dry Contact
    • Alarm
    • Output Overload
    • Low Battery
    • Battery Replacement
    • Low Input Voltage
  • Interfaces/Ports
    • Serial Port
    • Yes
    • USB
    • Yes
    • EPO Port
    • Yes
  • Battery Information
    • DC System Voltage
    • 48 V DC
    • Battery Characteristics
    • Internal Battery
    • Battery Chemistry
    • Lithium-Ion (LiFePO4)
    • Battery Capacity
    • 9000 mAh
    • Backup/Run Time (Full Load)
    • 6.50 Minute
    • Backup/Run Time (Half Load)
    • 14.50 Minute
    • Battery Life
    • 10 Year
    • Hot Swappable
    • Yes
    • Replaceable Battery
    • Yes
  • Environmental Conditions
    • Minimum Operating Temperature
    • 0°C
    • Maximum Operating Temperature
    • 40°C
    • Storage Temperature
    • -20°C - 60°C
    • Maximum Operating Elevation
    • 3 km
  • Physical Characteristics
    • Height
    • 85 mm
    • Width
    • 430 mm
    • Depth
    • 546 mm
    • Rack Height
    • 2U
    • Form Factor
    • Rack/Tower
    • Weight (Approximate)
    • 21 kg
  • Miscellaneous
    • Certifications & Standards
      • EC 61000-4-5
      • ANSI C62.41
      • Category B
      • IEC 62040-1:2008+A1 2013
      • IEC 62619 1st Ed
      • UL 1642 (Li-Ion Battery Cells)
      • UL 1973 (Li-Ion Battery Pack w/UPS)
      • IEC 62040-1:2008+A1 2013
      • IEC 62619 1st Ed
      • IEC 62040-2 2nd Ed
      • IEC 61000-3-2
      • IEC 61000-3-12
      • CISPR22
      • Class A
      • IEC 61000-4-5
      • ANSI C62.41
      • Category B
      • ISTA Procedure 2A
    • Environmental Compliance
    • Restriction of Hazardous Substances (RoHS) 2
    • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
    • Waste Electrical and Electronic Equipment Directive (WEEE)
    • Restriction of Hazardous Substances (RoHS)
